MongoDB $lookup Example | The MongoDB Aggregation Pipeline

This MongoDB $lookup tutorial is the first of a three-part aggregation query example that uses  the$lookup, $project$out stages. Download Studio 3T to get started

The $lookup aggregation stage

The aggregation pipeline stage $lookup makes it possible to join data from an input collection (the collection you’re running the query on) and a lookup collection (the collection you want data from), as long as both collections are on the same database.

Output documents from the lookup collection are added as embedded documents in the input collection.

In this tutorial, we will use the customers dataset as our input collection (download the .json file here) and the publicly-available Chicago affordable housing dataset as our lookup collection (download the .json file here).

Next, import the two datasets following these instructions and make sure that they are on the same database.

We’ll use an equality match example to illustrate the $lookup stage. An equality match requires that the input collection and the lookup collection have a field to match on.

(In our case, this is the address.zip_code field found in customers and the Zip Code field in housing.)

We want to show affordable housing options in the customers dataset as a new embedded field address.zip_code.affordable_housing_options, where there is a zip code match.

MongoDB $lookup in Aggregation Editor

An aggregation pipeline is meant to have multiple stages.

If you’re building more complex, multi-stage aggregation queries, we recommend using Aggregation Editor.  It lets you build queries stage by stage, check inputs and outputs, add, move, or delete stages as you go, and view your query in full mongo shell code.

Get Aggregation Editor by downloading the latest version of Studio 3T here.

1 – Right-click on the input collection and choose Open Aggregation Editor

In our example, the input collection is customers.

Add a new stage in Aggregation Editor

2 – Add a new stage

Click on the green plus icon in the toolbar, or the add a new stage link under Pipeline flow.

Add a new stage in Aggregation Editor

This will open a tab called Stage 1.

3 – Choose $lookup from the dropdown menu

Choose the MongoDB $lookup stage from the dropdown

4 – Run the aggregation query

Type your command in the Stage Editor section, following the syntax described.

Stage 1 with the MongoDB $lookup will look like:

      "from" : "housing",
      "localField" : "address.zip_code",
      "foreignField" : "Zip Code",
      "as" : "address.zip_code.affordable_housing_options"
  • housing is our lookup collection
  • address.zip_code is the field name in our input collection
  • Zip Code is the field name in our lookup collection
  • We’d like to create a new field address.zip_code.affordable_housing_options in our input collection. This is where we’ll embed the output documents from our lookup collection.

Execute the query by clicking on the play button (Execute full pipeline) in the toolbar.

Execute the query with MongoDB $lookup

5 – Check your results

For a quick visual check, the best way is to use Table View.

Click anywhere on the Results tab and choose Show All Embedded Fields. This expands all of address‘s embedded fields in the same view.

You should see our new field, affordable_housing_options.

Remember: We only have affordable housing information for Chicago zip codes, so not all customers will have values for this new field.

Click on the column header to sort the visible results in descending order.

Click on the column header to sort in descending order

Scroll to the left and you should see Maria Kelly as the first result, with 2 elements.

Right-click on the entry and choose Document > View Document (JSON).

You should see two affordable housing options nested under the zip_code field:

Two embedded documents, two affordable housing options

6 – View the full mongo shell code

The Aggregation Editor provides a more convenient interface for building queries, but you can always view the full mongo shell code at any point in the pipeline.

Click on the Query Code tab and choose mongo shell:

Click on Query Code to view the mongo shell code

This will show you the full MongoDB query which you can also run in IntelliShell, Studio 3T’s built-in mongo shell.

Click on the Open in IntelliShell button:

aggregation editor open intellishell

This directly opens the query in a separate IntelliShell tab:

Click on Execute full script

If you’re a pro at writing MongoDB queries, there’s also the hard(er) way of building aggregation queries: by manually writing them in the shell.

MongoDB $lookup in mongo shell

In case you haven’t yet, download the customers dataset as the input collection (download) and the publicly-available Chicago affordable housing dataset as the lookup collection (download). Import the two datasets following these instructions and make sure that they are on the same database.

If you’re running a single aggregation query that uses MongoDB $lookup, you can do so directly in IntelliShell using the following syntax:

            "$lookup" : {
                      from: "name of lookup collection",
                      localField: "field in the input collection",
                      foreignField: "field in the lookup collection",
                      as: "field name for the output documents"


1- Right-click on your database and choose Open IntelliShell

Make sure it’s the database containing your collections (in our example, chicago).

Open Aggregation Editor from the Connection Tree

2 – Run the aggregate query

In the Editor section, paste the $lookup aggregation query.

Our query in this case is:

            "$lookup" : {
                "from" : "housing",
                "localField" : "address.zip_code",
                "foreignField" : "Zip Code",
                "as" : "address.zip_code.affordable_housing_options"

Then, click on Execute entire script in the toolbar.

Click on Execute full script

3 – Check your results

This will give you the same results as Step 5 from Aggregation Editor.

As you will see in later examples, manually writing MongoDB aggregation queries can get quite cumbersome. Debugging, as you add more stages, will prove to be more difficult without a quick way to check inputs and outputs, which is a feature available in Aggregation Editor.

Next, we’ll add a second stage – $project – to filter our documents to only show the fields we want.

Read next: Stage 2 – MongoDB $project example
